A spiral classifier is a type of mechanical classification equipment used in mineral processing and other industries to separate solid particles in a slurry based on their size, density, and settling rates. It works by combining gravity sedimentation with mechanical lifting via a rotating spiral.
How a Spiral Classifier Works:
1. Feed Slurry Entry: A mixture of water and solid particles (slurry) is fed into the classifier’s inclined trough.
2. Sedimentation: Larger/heavier particles settle to the bottom due to gravity, while finer/lighter particles remain suspended.
3. Spiral Mechanism: A rotating spiral (auger) lifts the settled coarse material up the inclined trough and discharges it at the top as underflow (coarse product).
4. Overflow Discharge: The finer particles that do not settle are carried away by water flow as overflow (fine product).
Types of Spiral Classifiers:
1. High Weir Spiral Classifier
– Features a high weir at the overflow end to increase pool area for better settling.
– Suitable for coarser classification (e.g., sand washing).
2. Submerged Spiral Classifier
– The spiral operates below the liquid level, allowing for finer classification (common in closed-circuit grinding).
3. Single/Double Spiral Classifier
– Single-spiral: Smaller capacity, simpler design.
– Double-spiral: Higher capacity, more efficient for large-scale operations.
.jpg)
Applications:
– Mineral processing (e.g., iron ore, gold, copper).
– Sand washing and dewatering.
– Closed-circuit grinding systems.jpg)
all mill classification).
– Wastewater treatment (solids separation).
Advantages:
– Simple structure, low maintenance.
– Continuous operation with steady performance.
– Adjustable classification by changing spiral speed or weir height.
Disadvantages:
– Less precise than hydrocyclones for fine particle separation.
– Requires sufficient space due to its inclined design.
Key Parameters Affecting Performance:
– Spiral rotation speed.
– Slurry feed rate & density.
– Inclination angle of the trough.
– Weir height adjustment.
