# Key Mineral Processing Formulas for Iron Ore Beneficiation
Iron ore beneficiation involves several stages, including crushing, grinding, magnetic separation, flotation, and dewatering. To optimize these processes, engineers rely on various formulas to calculate efficiency, recovery rates, and other critical parameters. Below are some essential formulas used in iron ore processing.
—
## 1. Recovery (%)
Recovery measures the percentage of valuable material (iron) extracted from the ore.
Formula:
\[
\text{Recovery (\%)} = \left( \frac{\text{Weight of concentrate} \times \text{Grade of concentrate}}{\text{Weight of feed} \times \text{Grade of feed}} \right) \times 100
\]
Where:
– Weight of concentrate = Mass of final product (tonnes)
– Grade of concentrate = Fe content in concentrate (%)
– Weight of feed = Mass of raw ore processed (tonnes)
– Grade of feed = Fe content in raw ore (%)
—
## 2. Separation Efficiency (SE)
This evaluates the effectiveness of a separation process (e.g., magnetic separation).
Formula:
\[
SE (\%) = R_c – R_g
\]
Where:
– \(R_c\) = Recovery of valuable mineral (Fe) in concentrate (%)
– \(R_g\) = Recovery of gangue (waste material) in concentrate (%)
A higher SE indicates better separation performance..jpg)
—
## 3. Bond Work Index (Wi)
Used to estimate energy requirements for grinding iron ore.
Formula:
\[
W_i = 10 \times \left( \frac{W}{\sqrt{P_{80}}} – \frac{W}{\sqrt{F_{80}}} \right)
\]
Where:
– \(W\) = Specific energy consumption (kWh/t)
– \(P_{80}\) = 80% passing size of product (µm)
– \(F_{80}\) = 80% passing size of feed (µm)
A lower Wi means easier grindability.
—
## 4. Tromp Curve for Density Separation
Evaluates efficiency in gravity-based separation methods like jigging or spirals. The curve plots partition coefficients against density fractions.
—.jpg)
## 5. Magnetic Suscept
