Here’s a general specification outline for a Rotor Hammer Mill (RHM) based on common industry standards. Actual specifications may vary depending on the manufacturer and model.
Rotor Hammer Mill (RHM) Specifications
# 1. General Specifications
– Model: RHM (Rotor Hammer Mill)
– Type: Horizontal or Vertical (depending on design)
– Application: Grinding/crushing of grains, biomass, feed, minerals, etc.
– Power Source: Electric motor or diesel engine
# 2. Technical Parameters
| Parameter | Specification |
|———–|————–|
| Capacity | 1–50 TPH (varies with material and screen size) |
| Rotor Speed | 1500–3000 RPM |
| Hammers | 4–48 pieces (replaceable, hardened steel) |
| Screen Size | 0.5–10 mm (adjustable) |
| Motor Power | 7.5–500 kW (10–670 HP) |
| Inlet Size | Customizable (e.g., 200×200 mm to 1000×1000 mm) |
| Outlet Size | Adjustable based on screen |
.jpg)
# 3. Construction & Materials
– Body Material: Heavy-duty steel or stainless steel
– Hammers: Hardened steel or tungsten car
e-tipped
– Bearings: Heavy-duty, self-aligning bearings for high load capacity
# 4. Features
– Adjustable grinding fineness via interchangeable screens
– Easy maintenance with quick-access doors
– Dust extraction port for pneumatic discharge
– Overload protection system
# 5. Optional Accessories
– Cyclone separator for dust control
– Magnetic separator to remove metal contaminants
– Variable frequency drive (VFD) for speed control
