The electromagnetic separation of minerals from gold is a specialized beneficiation technique used to separate conductive or magnetic minerals from non-conductive/non-magnetic ones (such as native gold or gold-bearing ores). Since gold itself is not strongly magnetic, this method is typically used to remove associated minerals (e.g., iron oxides, sulfides, or other magnetic impurities) before further gold extraction.
How Electromagnetic Separation Works
1. Principle
– Magnetic minerals (e.g., magnetite, pyrrhotite) are attracted by a magnetic field.
– Non-magnetic or weakly magnetic materials (including free gold) remain unaffected.
– If gold is alloyed with ferromagnetic metals (rare), it may show slight magnetism.
2. Equipment Used
– Low-Intensity Magnetic Separators (LIMS): For ferromagnetic minerals like magnetite.
– High-Intensity Magnetic Separators (HIMS): For paramagnetic minerals (e.g., hematite, ilmenite).
– Electrostatic Separators: Useful when differences in electrical conductivity exist (e.g., sulfide vs. free gold).
3. Process Steps in Gold Ore Processing
– Crushing & Grinding: Ore is reduced to fine particles to liberate gold and associated minerals.
– Pre-concentration: Magnetic separation removes iron-rich gangue before cyanidation or gravity separation.
– Separation of Sulfides: If gold is locked in sulfide minerals (e.g., pyrite), electromagnetic methods may help isolate them for further treatment.
Limitations for Gold Recovery
– Gold itself is diamagnetic (repelled by magnetic fields), so electromagnetic separation cannot directly recover free gold.
– Best suited for removing interfering magnetic impurities before leaching or gravity concentration.
.jpg)
Alternative Methods for Gold Separation
1. Gravity Separation (Shaking tables, centrifugal concentrators) – Effective for coarse free gold.
2. Froth Flotation – For fine gold locked
sulfides.
3. Cyanidation/Leaching – Chemical dissolution of liberated gold.
Conclusion
Electromagnetic separation is primarily a pre-concentration step to remove magnetic gangue from gold ores rather than isolating pure gold directly. For efficient recovery, it’s often combined with gravity separation or hydrometallurgical methods.
