The DMC Pulse Bag Dust Catcher is a widely used dust collection system in industries such as metallurgy, mining, cement, and chemical processing. It efficiently captures and filters airborne dust particles using pulse-jet cleaning technology. Below are its key features, working principle, and applications:
Key Features:
1. Pulse-Jet Cleaning System
– Uses compressed air to periodically clean filter bags, ensuring high efficiency and low maintenance.
– Automatic or manual control options for cleaning cycles.
2. High Filtration Efficiency (up to 99.9%)
– Suitable for fine particulate matter (0.1–20 microns).
3. Durable Filter Bags
– Made from polyester, nomex, or other high-temperature-resistant materials.
4. Compact & Modular Design
– Available in different sizes (e.g., DMC-24, DMC-36, DMC-48) based on bag quantity.
5. Low Pressure Drop & Energy Saving
– Optimized airflow design reduces energy consumption.
6. Wide Temperature Range
– Can handle gases up to 120–200°C (depending on filter material).
Working Principle:
1. Dust-Laden Air Inlet – Polluted air enters the chamber.
2. Filtration – Dust particles are trapped on the outer surface of filter bags.
3. Pulse Cleaning – Compressed air blasts dust off the bags into a hopper.
4. Clean Air Outlet – Filtered air exits through the top.
5. Dust Discharge – Collected dust is removed via a rotary valve or screw conveyor.
Applications:
– Cement plants (raw mill, kiln, clinker cooler)
– Steel & foundry industries
– Power plants (coal dust collection)
– Cheml & pharmaceutical industries
– Woodworking & grain processing
Advantages Over Other Dust Collectors:
✔ Higher filtration efficiency than cyclones or wet scrubbers
✔ Lower operational cost compared to electrostatic precipitators
✔ Suitable for continuous operation with minimal downtime
