The calcium carbonate powder grinding mill process involves several stages to transform raw calcium carbonate (CaCO₃) into fine or ultrafine powder for industrial applications. Here’s a detailed breakdown:
.jpg)
1. Raw Material Preparation
– Source: Calcium carbonate is derived from natural minerals (limestone, marble, chalk) or synthesized chemically.
– Crushing: Large chunks are crushed into smaller particles (5–20 mm) using a jaw crusher or hammer crusher.
.jpg)
2. Grinding Process
The crushed material is fed into a grinding mill for fine pulverization. Common mills used include:
# a) Ball Mill
– Principle: Uses steel balls to crush and grind material via rotation.
– Output: 200–400 mesh (74–37 µm).
– Features: Suitable for coarse to medium grinding; wet or dry processing.
# b) Raymond Mill (Roller Mill)
– Principle: Grinds material between rotating rollers and a ring.
– Output: 80–325 mesh (180–45 µm).
– Features: Energy-efficient for medium-fine powder.
# c) Vertical Roller Mill (VRM)
– Principle: Uses hydraulic pressure to grind material between rollers and a rotating table.
– Output: 200–1000 mesh (74–10 µm).
– Features: High efficiency, low energy consumption.
# d) Ultrafine Grinding Mill (HGM Series)
– Principle: Uses multiple rollers and classifiers for superfine grinding.
– Output: 325–2500 mesh (45–5 µm).
– Features: Produces ultrafine powder for high-value applications.
# e) Jet Mill (Air Classifier Mill)
– Principle: Uses high-speed air jets to collide particles.
– Output: 1–20 µm (D97).
– Features: No contamination, ideal for ultra-pure powders.
3. Classification & Separation
After grinding, the powder passes through:
– A classifier (e.g., air classifier or cyclone separator) to ensure uniform particle size.
– Oversized particles are returned for regrinding.
4. Surface Modification (Optional)
For specialized applications, the powder may undergo:
– Coating with stearic acid or silane to improve compatibility in plastics, rubber, or paints.
5. Packaging & Storage
The final product is
